Live the freedom that your work demands
Efficiency champion for drilling holes fast with just one battery charge
Better protection by KickBack Control and Vibration Control
Optimized brushless motor and mechanism for faster work
Compatible with dust extractor solution GDE 18V-16
Battery status at a glance on HMI and smart app for customized setting
TECHNICAL DATA
Additional data
Impact energy (according to EPTA 05/2016)
2.4 J
Weight excl. battery
2.9 kg
Impact rate at rated speed
0 – 4,350 bpm
Rated speed
0 – 980 rpm
Tool holder
SDS plus
Drilling range
Hammer drilling diameter range in concrete
4 – 24 mm
Recommended drilling diameter range in concrete
6 – 14 mm
Max. drilling diameter in metal
13 mm
Max. drilling diameter in wood
30 mm
Noise/vibration information
Sound pressure level
91.5 dB(A)
Sound power level
102.5 dB(A)
Uncertainty K
3 dB
The A-rated noise level of the power tool is typically as follows: Sound pressure level dB(A); Sound power level dB(A). Uncertainty K= dB.
